1550nm Acousto-optic Modulator,

Fiber Coupled and Free Space: Low insertion loss, compact, Stable performance,General performance parameters

1550nm 80MHz Fiber Coupled Acousto-optic Modulator

1550nm 80MHz fiber coupled acousto-optic modulator

Material: TeO2
Wavelength: 1550nm
Average optical power: 1W
Peak (pulse) optical power: 1kW
Ultrasonic sound velocity: 4200 m/s
Insertion loss: 3.5dB
Extinction Ratio: 50dB
Return loss: 40 dB
Rising edge time: 30ns
frequency: 80MHz
Frequency shift: +/-80MHz
RF power: 2.5W
Voltage standing wave ratio: 1.2:1
input resistance: 50Ω
Device interface: SMA
Fiber type: PM/SM
Fiber length: 1m
Fiber interface : F/APC
Operating temperature: -20~+60 ℃
Storage temperature: -30~+70℃
