Laser optical collimating lens focusing lens 400-700nm EFL8mm

Laser optical collimating lens focusing lens 400-700nm  EFL8mm

Collimating lens is an instrument that converts light from each point in the aperture column into a parallel column of collimating light.Lens type depends on aberration requirements,For low requirements, simple lenses, such as flat convex or double convex lenses, maybe used and a larger relative aperture is allowed.High requirements,Achromatic lens will be use, the relative aperture is also appropriately reduced.

specification

Mount Size:M8*P0.5*8mm or M9*0.5*8mm
Lens Material:D-ZK3
Wavelength:530nm
Focal Length:8mm
NA:0.25
Working Distance:5.44mm
CA:0.25mm
Transmission>95%
Coating:BBAR 400-700nm
